Explosion Proof Fans
Explosion-proof fans are industrial fans that are engineered to operate safely in hazardous environments where flammable gases, vapors, dust, or other combustible materials may be present. These fans are constructed with fire resistant materials and feature sealed motors, spark-resistant blades, and other safety features to prevent ignition sources that could lead to an explosion. Explosion-proof fans are used in applications such as chemical processing, oil and gas operations, mining, and grain handling, where the risk of explosive atmospheres is high. By providing safe ventilation and air movement in these critical environments, explosion-proof fans help protect both workers and equipment from potential hazards.
- CFM: Up to 169,500 CFM
- Static Pressure: Up to 80 in. WG
- Spark Resistant Construction – AMCA Type A, B, and C is available,
- Membrane Type shaft seal is standard with AMCA Spark Resistant Construction.
- Explosion Proof Motors are also available.
- HARTZELL
- CINCINNATI FAN
- IAP
- PDF DOWNLOADS
| Model | Type | Material | Airflow | Static Pressure |
|---|---|---|---|---|
| Series 03/03P/03U/03M | Centrifugal, Backward Curved | Steel, Stainless Steel, Aluminum | Up to 169,500 CFM | Up to 20” WG |
| Series 40 | Inline Centrifugal Blowers Belt Drive | Fiberglass Reinforced Plastic (FRP) | Up to 75,000 CFM | Up to 16” WG |
| Series 41/41P/41U | Fiberglass Backward Curved Centrifugal Fan | Fiberglass Reinforced Plastic (FRP) | Up to 120,000 CFM | Up to 30” WG |
| Series 42 | Fiberglass Radial Blower | Fiberglass Reinforced Plastic (FRP) | Up to 1,500 CFM | Up to 12” WG |
| Series 43 | Fiberglass Radial Blower | Fiberglass Reinforced Plastic (FRP) | Up to 11,500 CFM | Up to 16” WG |
| Series 34 | Fiberglass Belt Drive Duct Axial Fan | Fiberglass Reinforced Plastic (FRP) | Up to 60,000 CFM | Up to 3” WG |
| Series 04 | Backward Curved In-LIne Centrifugal Steel Fan | Steel | Up to 75,000 CFM | Up to 14” WG |
| Series 12 | Plug Fan | Steel, Stainless Steel, Aluminum | Up to 28,000 CFM | Up to 12” WG |
| Series 0/05F | Backward Inclined Centrifugal Fan Industrial Exhauster | Steel, Stainless Steel, Aluminum | Up to 46,000 CFM | Up to 46” WG |
| Series 39 | Direct Drive TubeAxial Fan, Spark Resistant | Carbon Steel, Stainless Steel, Aluminum, Hot Dip Galvanized | Up to 59,000 CFM | Up to 2.5” WG |
| Series 07T/07M | Backward Inclined Turbo Pressure Blower, Spark Resistant | Steel, Stainless Steel, Aluminum | Up to 1,600 CFM | Up to 14” WG |
Please contact us for details on our full backward curved fan selection, additional models are available!
| Model | Type | Material | Airflow | Static Pressure |
|---|---|---|---|---|
| Model PMC | Pressure Blower | Carbon Steel, Stainless Steel, Aluminum, Coated Steel | 100 to 15,000 CFM | Up to 80 in. WG |
| Model CIM | Centrifugal Inline Fan | Carbon Steel, Stainless Steel, Coated Steel | 500 to 35,000 CFM | Up to 6 in. WG |
| Model EBM & EBR | Portable Fume Exhauster-Blower | Spark Resistant Construction | Up to 985 CFM | Up to 9.8 in. WG |
| Model 33S, 50S, 75S, 100S, 150S, 200S, 300S | Dust Collectors | Cast Aluminum, Steel Blower Housing | up to 1300 CFM | Up to 10 in WG |
| Model AC | Air Circulators | Carbon Steel, Stainless Steel, Aluminum, Coated Steel | 500 to 20,000 CFM | Up to 2 in. WG |
| Model PF | Plug Fan for Air Handling Units | Carbon Steel, Stainless Steel, Coated Steel | 500 to 50,000 CFM | Up to 6 in. WG |
| Model BAF | Backward Inclined Airfoil Centrifugal Fan | Carbon Steel, Stainless Steel, Aluminum, Coated Steel | 500 to 60,000 CFM | Up to 3 in. WG |
| Model TAF | Tubeaxial Fan | Carbon Steel, Stainless Steel, Coated Steel | 1,000 to 70,000 CFM | Up to 5 in. WG |
| Model WAF | Wide Airfoil Centrifugal Fann | Carbon Steel, Stainless Steel, Coated Steel | 1,000 to 100,000 CFM | Up to 12 in. WG |
| Model HTF | High Temperature Centrifugal Fan | Heat-resistant Carbon Steel or Stainless Steel | 500 to 35,000 CFM | Up to 10 in. WG |
| Model DDF | Direct Drive Tube Axial Fan | Carbon Steel, Stainless Steel, Aluminum, Coated Steel | 1,000 to 100,000 CFM | Up to 10 in. WG |
Please contact us for details on our full backward curved fan selection, additional models are available!
| Model | Type | Material | Airflow | Static Pressure |
|---|---|---|---|---|
| Type B Fan. Spark Resistant | Backward Inclined Centrifugal Fan | Carbon Steel; Optional Materials:Stainless Steel and Aluminum; Special coatings available | 500 to 100,000 CFM | Up to 10 in. WG |
Please contact us for details on our full backward curved fan selection, additional models are available!
Things to Consider When Buying Explosion Proof Fans
When buying explosion-proof fans, consider the hazardous location classification (Class, Division, and Group) to ensure compliance with NFPA and OSHA regulations. Look for fans with explosion-proof motors, spark-resistant construction, and corrosion-resistant materials if used in harsh environments. Verify the fan’s airflow capacity (CFM) and static pressure rating to match the facility’s ventilation needs. Additionally, ensure proper certification (e.g., UL, ATEX) and assess mounting options (wall, roof, duct) for optimal placement. Choosing a fan with durable components and low maintenance requirements will enhance safety and efficiency in hazardous environments.
J.E. Phillips Company Serves Explosion Proof Application Needs
J.E. Phillips Company serves a wide range of industries with explosion proof fans engineered to meet specific needs. We are proud to partner with Hartzell, Cincinnati Fan, IAP, Daniels Fans to offer explosion proof fans in configurations to meet a wide array of application needs.
